| Memory |
| Non-ECC | Yes |
| Maximum internal memory | 4 GB |
| Supported memory clock speeds | 1066,1333,1600,1866 MHz |
| Number of DIMM slots | 4 |
| Supported DIMM module capacities | 1GB,2GB,4GB,8GB,16GB |
| Memory channels support | dual |
| Supported memory types | DDR3 |
| Processor |
| Processor family | AMD |
| Processor socket | Socket FM1 |
| Maximum number of SMP processors | 1 |
| Internal I/O |
| Number of COM connectors | 1 |
| USB 3.0 connectors | 1 |
| Power fan connector | Yes |
| Front panel audio connector | Yes |
| S/PDIF out connector | Yes |
| Number of chassis fan connectors | 2 |
| Peripheral (Molex) power connectors (4-pin) | 1 |
| CPU fan connector | Yes |
| ATX Power connector (24-pin) | Yes |
| Number of Parallel ATA connectors | 0 |
| Number of SATA 3 connectors | 6 |
| USB 2.0 connectors | 2 |
| Back panel I/O ports |
| IEEE 1394/Firewire ports quantity | 0 |
| Speaker/ headphone/ line-out jack | 6 |
| VGA (D-Sub) ports quantity | 0 |
| Ethernet LAN (RJ-45) ports quantity | 1 |
| eSATA ports quantity | 0 |
| HDMI ports quantity | 0 |
| USB 2.0 ports quantity | 6 |
| PS/2 ports quantity | 2 |
| Digital audio optical out | 1 |
| USB 3.0 ports quantity | 2 |
| DVI-D ports quantity | 0 |
| Technical details |
| Motherboard form factor | ATX |
| Motherboard chipset | AMD A75 |
| Parallel processing technology support | CrossFire |
| Proper use | PC |
| Cables included | SATA |
| Overclocking features | ASUS C.P.R.(CPU Parameter Recall) |
| Source data-sheet | Icecat.biz |
| Audio |
| Audio output channels | 7.1 |
| Audio system | Realtek ALC 892 |
| Expansion slots |
| PCI slots | 3 |
| PCI Express x16 slots | 2 |
| PCI Express x1 slots | 2 |
| PCI Express slots version | 2.0 |
| BIOS |
| BIOS type | UEFI |
| Storage controllers |
| Controller interface type | AMD A75 |
| RAID levels | 0,1,10,JBOD |
| Networking |
| Ethernet interface type | Gigabit |
| Operating system/software |
| Bundled software | ASUS PC Probe II
ASUS Update |
| BIOS |
| BIOS memory size | 32 MB |
| Operating system/software |
| Trial software | Anti-virus |
| Weight & dimensions |
| Width | 305 mm |
| Video |
| Graphics adapter family | AMD |
| Packaging content |
| Quick installation guide | Yes |
| BIOS |
| ACPI version | 2.0a |
| Operating system/software |
| Drivers included | Yes |
| Video |
| Integrated graphics adapter (UMA/GMA) | Yes |
| Weight & dimensions |
| Depth | 224 mm |
| Networking |
| LAN controller | Realtek RTL8111E |
| Video |
| Graphic adapter | Radeon HD 6000 |
| Other features |
| Compatible operating systems | - |
